DC Drive transparent

DC Drives

EPD offers a well-curated collection of variable speed drive systems that deliver superior control for speed and torque for DC motors, such as those in conveyors, fans, pumps, winches, drilling systems, propulsion systems and more.

Our DC drive solutions provide variable speed control for DC motors and are ideal for applications requiring low speed control, torque and power.

DC Drives

EPD offers a well-curated collection of variable speed drive systems that deliver superior control for speed and torque for AC motors, such as those in conveyors, fans, pumps, winches, drilling systems, propulsion systems and more.

Our DC drive solutions provide variable speed control for DC motors and are ideal for applications requiring low speed control, torque and power.

DC Drive transparent

DC DRIVE TECHNOLOGY: DYNAMIC, RUGGED AND COST-EFFECTIVE

Depending on the application, DC drives are frequently the most favorably-priced drive solution. They have many advantages when it comes to reliability, operator friendliness and operating characteristics. There are many good technical and economic reasons for using DC drives, such as:

Favorably-priced four quadrant operation

Continuous operation at a low speed

Full torque even at low speeds

High starting torque

Wide speed control range with constant power

Low space requirement and low weight

IEC / UL
VFD Power Ratings kW (hp)0.55kW - 5300kW ( .73 - 7105 hp )
Rated Operational Voltage208V, 240V, 380V, 500V, 525V, 690V
Enclosure Ingress ProtectionIP 21, IP 22, IP 23, IP 31, IP 54
CoolingAir cooled, Liquid cooled
CommunicationMetasys N2, Modbus RTU, PROFIBUS DP V1, PROFINET, DeviceNet, CANopen, LONworks, BACnet (MSTP), Modbus TCP, EtherNet/IP, EtherCAT
ApplicationsPumps, Fans, Compressors, Conveyors , Process / Material Treatment, Mills / Drums / Kilns, Winding, Unwinding, Drilling, Propulsion / Thrusters, Winches, Vertical & horizontal movement, Power conversion & power generation, Positioning / Synchronization
Harmonic ContentTHDᵢ < 5% topology - dependent
Topology6-pulse, phase-shifted multi-pulse, passive/active harmonic mitigation, common DC bus
  • Flexible, Expandable, Functional and Performance-Driven

  • Easy Commissioning and Parameterization

  • Approvals: ABS

  • High-Functional Safety

  • Seamless Integration

  • Replaceable Components
